Nominal sizes DN

DN40、DN50

Connections

PN16/25&ANSI150 RF or RTJ according to ASME B16.5

Design pressure

5 bar for diaphragm balance valve
20 bar for piston balance valve

Range of downstream pressure Wd

from 15 to 4000 mbar

Accnracy class AC

up to 5

Lock-up pressure class SG

up to 10

Minimum working differential pressure

0.5 bar

Design temperature

from -20℃ to +60℃

Key benefits

· High flow coefficient
· High accuracy, even at high flow rates
· Reduced lock-up pressure zone and lock-up pressure
· Reduced response time, no internal leakage at zero flow rate
· Fail to open
· Periodic maintenance without disassembling the valve from the pipework
· Ability to retrofit the SD100 or SD400 slam-shut OPSO/UPSO, without modifying the existing piping
